Building a GBT library from scratch to understand what’s actually happening under the hood, and to have the flexibility to experiment with new ideas.
Author

Nima Sarang

Published

December 14, 2025

1 Introduction

In my line of work, Gradient Boosted Trees (GBTs) algorithms such as LightGBM, XGBoost, and CatBoost are the go-to models for tabular data. Not only are they great for fast prototyping, but they also deliver a strong baseline performance that is hard to beat. Having said that, these libraries are complex pieces of software that don’t offer the flexibility to customize and apply research ideas. I often found myself spending hours going through thousands of lines of source code, only to be more confused at the end. Granted, the maintainers have a high incentive to optimize for accuracy and speed, not so much for code readability and extensibility.

That’s why I decided to implement my own GBT library from scratch, with a balance between simplicity and functionality. I’ve gone through the original papers, and made a decision to implement the components that I find most essential. There’s always room for improvement but I didn’t want to make it too complex, as that would reduce its educational value.

NoteNote

This is the second post in my “From Scratch” series. The first covered implementing LSTMs using only NumPy here.

2 What you’ll find here

In this post I’ll walk through the implementation of each component one by one. The following features have been implemented:

  1. Histogram-based splitting [LightGBM/XGBoost style]
  2. Multi-output decision trees
    • Supports multivariate regression, multi-class classification, and uncertainty estimation
  3. Leaf-wise binary tree growth [LightGBM]
  4. Categorical feature handling
    • via ordered target statistics [CatBoost]
    • via gradient-based ordering, i.e. Fisher’s statistics [LightGBM]
  5. L1 and L2 regularization
  6. Gradient-based One-Side Sampling (GOSS) [LightGBM]
  7. Data subsampling
  8. Automatic handling of missing values. Use np.nan to designate missing values [XGBoost]
    • Evaluate gain for directing nulls to left vs right child at each split
  9. Path smoothing with exponential-decaying weights
    • Regularize leaf predictions by blending with ancestor values along the path

One thing I found interesting is how much these libraries have evolved since their original publications, and how much they borrow ideas from each other. For example, if you were to use LightGBM and XGBoost using their default parameters, you’d find they’re functionally very similar.

3 The math

This is a refresher for the math behind GBTs, which I’ll try to keep brief. The main idea is to sequentially add decision trees to an ensemble, where the objective is to minimize the difference between the true labels and the output of the existing ensemble using gradient descent:

\[ \min_{F} \sum_{(x, y) \in \mathcal{D}} \mathcal{L}\left(y, F(x)\right) \tag{1}\]

where \(\displaystyle F_m(x) = \sum_{i=0}^{m} T_i(x)\) is an additive ensemble of trees. Since we’re optimizing over functions (trees) rather than parameters, this approach is termed functional gradient descent.

At iteration \(k\), given current predictions \(F_{k-1}(x)\), we fit a new tree \(T_k(x)\) that moves us in the direction of reducing \(\mathcal{L}\). Using a second-order Taylor approximation (Newton-Raphson), for a sample \((x_i, y_i)\) we have:

\[ J = \mathcal{L}(y_i, F_{k-1}(x_i) + T_k(x_i)) \approx \mathcal{L}(y_i, F_{k-1}(x_i)) + g_i T_k(x_i) + \frac{1}{2} h_i T_k^2(x_i) \tag{2}\]

where \(g_i = \frac{\partial \mathcal{L}}{\partial F}\) (gradient) and \(h_i = \frac{\partial^2 \mathcal{L}}{\partial F^2}\) (Hessian). Since the first term is constant with respect to \(T_k\), we only need to minimize \(g_i T_k(x_i) + \frac{1}{2} h_i T_k^2(x_i)\). For samples in a leaf node \(S\), the optimal output value \(v = T_k(x_i) \quad\forall x_i \in S\) is found by setting the derivative of Eq. 2 to zero:

\[ \displaystyle\frac{\partial}{\partial v} \sum_{i \in S} \left(g_i v + \frac{1}{2} h_i v^2\right) = 0 \implies v = -\frac{\sum_{i \in S} g_i}{\sum_{i \in S} h_i} \tag{3}\]

We can also add an L2 regularization term \(\frac{1}{2} \lambda v^2\) to penalize large magnitude values, with \(\lambda\) being the strength hyperparameter. The loss function becomes:

\[ J_S = \sum_{i \in S} \left(g_i v + \frac{1}{2} h_i v^2\right) + \frac{1}{2} \lambda v^2 \tag{4}\]

and consequently, the optimal leaf value becomes:

\[ v = -\frac{\sum_{i \in S} g_i}{\sum_{i \in S} h_i + \lambda} \tag{5}\]

Note that this is even before we considered how to split the tree nodes, but Eq. 5 stands on its own for a fixed tree structure. We can use the leaf value to compute the contribution of a node to the overall loss reduction, by substituting \(v\) from Eq. 5 into Eq. 4, and negating it:

\[ \text{Gain}(S) = \frac{1}{2} \frac{(\sum_{i \in S} g_i)^2}{\sum_{i \in S} h_i + \lambda} \]

\(Gain(S)\) represents how much the loss would decrease if we created a node covering subset \(S\) of samples in the dataset. Using this, we can evaluate the contribution of a node split by adding the contributions of its two child nodes and subtracting the parent node’s contribution, since the parent node will no longer be a leaf after the split. Assuming \(L \subseteq S\) and \(R = S \setminus L\) are the left and right child nodes after the split, the gain from the split is:

\[ \text{SplitGain}(S, L, R) = \text{Gain}(L) + \text{Gain}(R) - \text{Gain}(S) \tag{6}\]

SplitGain is what we maximize during tree construction, and \(>0\) is the minimum threshold for a split to be considered beneficial. At each node, we evaluate all features and all possible split thresholds, and select the split with the highest gain. Then, among all node candidates to split, we select the one with the highest SplitGain to actually perform the split. This is called leaf-wise growth.

To extend this to multi-output settings, we could either build separate trees for each output, or, what I implemented here is to treat \(T(x)\), \(v\), \(g_i\), and \(h_i\) as vectors. The derivations remain mostly the same, except that we now sum over the per-output gain to get the overall gain.

4 Implementation

The source code is organized into the following modules, which I’ll go through one by one in order:

  1. Gradient Boosted Model (GBM): The model class that ties everything together.
  2. Data Preprocessing: Preprocessing categorical and numerical features, and preparing data for training and inference.
  3. Node and Tree Structures: Data structures for decision tree and its nodes.
  4. Tree Optimization: The core logic for fitting decision trees using histogram-based splitting and leaf-wise growth.
  5. Loss Functions and Distributions: Implementing loss functions.
  6. Utility Functions: A few utility functions used throughout the code.

4.1 Gradient Boosted Model (GBM)

This is the main class that ties everything together. It initializes the distribution, data handler, and manages the training process. I think it’s helpful to have a high-level view first before diving into the implementation of each component. The API deliberately mirrors the fit/predict pattern from scikit-learn and familiar GBT libraries but the internals are simple enough to experiment with.

gbm.py

#

Required imports

1import numpy as np
2import pandas as pd
3from tqdm.auto import tqdm
#

DataPreprocessor handles feature encoding and binning and train/test transformations

4from .data import DataPreprocessor
5from .distributions import Distribution
#

TreeGrower handles the logic of growing individual trees

6from .grower import TreeGrower
7from .utils import trunc
#

Gradient Boosted Model (GBM)

This is the user-facing class for training and making predictions.

Parameters

  • distribution : Distribution
    • The loss distribution to optimize.
  • learning_rate : float, default=0.1
    • The learning rate (shrinkage factor) for each tree's contribution.
  • n_trees : int, default=100
    • The number of trees to grow in the ensemble.
  • n_leaves : int, default=20
    • The maximum number of leaves per tree.
  • max_depth : int, default=6
    • The maximum depth of each tree.
  • min_samples_split : int, default=2
    • The minimum number of samples required to split a node.
  • min_weight_leaf : float, default=20
    • The minimum sum of instance weights required in a leaf node for a split to be considered.
  • min_gain_to_split : float, default=0.0
    • The minimum gain required to perform a split. Referred to as \(\gamma\) in some literature.
  • objective_weight : List[float], optional
    • Weights for multi-output objectives. If the distribution is multivariate, this specifies the relative importance of each output dimension.
  • l1_regularization : float, default=0.0
    • L1 regularization term on leaf values.
  • l2_regularization : float, default=0.0
    • L2 regularization term on leaf values.
  • feature_fraction : float, default=1.0
    • The fraction of features to subsample for each tree (Values between 0 and 1). This helps with regularization.
  • samples_fraction : float, default=1.0
    • The fraction of training samples to subsample for each tree. Values between 0 and 1.
  • goss_top_rate : float, optional
    • Whether to use GOSS sampling. If set, specifies the top fraction of samples (by absolute gradient) to keep.
  • goss_bottom_rate : float, optional
    • If using GOSS, specifies the bottom fraction of samples (by absolute gradient) to keep.
  • goss_rescale_bottom : bool, optional
    • Whether to rescale the weights of the bottom samples in GOSS to maintain the overall weight sum.
  • path_smoothing_strength : float, default=0.0
    • Strength of path smoothing to apply to leaf values after tree is grown.
  • max_bins : int, default=255
    • The maximum number of bins to use for numerical features.
  • max_categories : int, default=100
    • The maximum number of unique categories for a feature to be treated as categorical. Otherwise, it is encoded as numerical using label encoding.
  • n_permutations : int, default=10
    • Number of random permutations to use for ordered target statistics encoding of categorical features (CatBoost-style).
  • prior_strength : float, default=1.0
    • The strength of the prior for target statistics encoding.
  • seed : int, optional
    • Random seed for reproducibility.
  • verbose : bool, default=True
    • Whether to print progress messages during training.
 8class GradientBoostedModel:
 9    def __init__(
10        self,
11        distribution: Distribution,
12        learning_rate: float = 0.1,
13        n_trees: int = 100,
14        n_leaves: int = 20,
15        max_depth: int = 6,
16        min_samples_split: int = 2,
17        min_weight_leaf: float = 20,
18        min_gain_to_split: float = 0.0,
19        objective_weight: list[float] = None,
20        l1_regularization: float = 0.0,
21        l2_regularization: float = 0.0,
22        feature_fraction: float = 1.0,
23        samples_fraction: float = 1.0,
24        goss_top_rate: float = None,
25        goss_bottom_rate: float = None,
26        goss_rescale_bottom: bool = False,
27        path_smoothing_strength: float = 0.0,
28        max_bins: int = 255,
29        max_categories: int = 100,
30        n_permutations: int = 10,
31        prior_strength: float = 1.0,
32        seed: int = None,
33        verbose: bool = True,
34    ):
35        self.distribution = distribution
36        self.learning_rate = learning_rate
37        self.n_trees = n_trees
38        self.n_leaves = n_leaves
39        self.max_depth = max_depth
40        self.min_samples_split = min_samples_split
41        self.min_weight_leaf = min_weight_leaf
42        self.min_gain_to_split = min_gain_to_split
43        self.objective_weight = objective_weight
44        self.l1_regularization = l1_regularization
45        self.l2_regularization = l2_regularization
46        self.feature_fraction = feature_fraction
47        self.samples_fraction = samples_fraction
48        self.goss_top_rate = goss_top_rate
49        self.goss_bottom_rate = goss_bottom_rate
50        self.goss_rescale_bottom = goss_rescale_bottom
51        self.path_smoothing_strength = path_smoothing_strength
52        self.max_bins = max_bins
53        self.max_categories = max_categories
54        self.n_permutations = n_permutations
55        self.prior_strength = prior_strength
56        self.seed = seed
57        self.verbose = verbose
#

Attributes to be set during fitting

58        self.data_processor_ = None
59        self.initial_params_ = None
60        self.trees_ = []
61        self.is_fitted_ = False
#

Fit the Gradient Boosted Model to the data. This method should give you a high-level overview of the training process.

  • X : pd.DataFrame
    • The input features.
  • y : np.ndarray
    • The target values.
  • sample_weight : np.ndarray, optional
    • Sample weights for each instance.
62    def fit(self, X: pd.DataFrame, y: np.ndarray, sample_weight: np.ndarray = None):
63        if sample_weight is None:
64            sample_weight = np.ones(len(X))
#

Preprocess data and compute feature info

65        self.data_processor_ = DataPreprocessor(
66            max_categories=self.max_categories,
67            max_bins=self.max_bins,
68            n_permutations=self.n_permutations,
69            prior_strength=self.prior_strength,
70            seed=self.seed,
71        )
72        self.data_processor_.fit(X, y, sample_weight)
#

Transform input data into numerical array

73        inputs, targets = self.data_processor_.transform(
74            X, y, sample_weight, mode="train"
75        )
#

Initialize tree grower. This handles the logic of growing individual trees.

76        grower = TreeGrower(
77            distribution=self.distribution,
78            learning_rate=self.learning_rate,
79            objective_weight=self.objective_weight,
80            l1_regularization=self.l1_regularization,
81            l2_regularization=self.l2_regularization,
82            min_weight_leaf=self.min_weight_leaf,
83            max_leaves=self.n_leaves,
84            max_depth=self.max_depth,
85            goss_top_rate=self.goss_top_rate,
86            goss_bottom_rate=self.goss_bottom_rate,
87            goss_rescale_bottom=self.goss_rescale_bottom,
88            feature_fraction=self.feature_fraction,
89            samples_fraction=self.samples_fraction,
90            min_samples_split=self.min_samples_split,
91            min_gain_to_split=self.min_gain_to_split,
92            seed=self.seed,
93        )
#

Initialize the ensemble. Query the Distribution object for initial parameters.

94        self.initial_params_ = self.distribution.init_params(y)
95        predictions = np.full((len(y), len(self.initial_params_)), self.initial_params_)
#

Print initial loss

96        if self.verbose:
97            loss = -self.distribution.log_prob(y, predictions).sum()
98            print(f"Initial loss: {trunc(loss)}")
#

Grow trees one by one

 99        for i in tqdm(range(self.n_trees)):
100            tree = grower.grow(
101                inputs=inputs,
102                features_info=self.data_processor_.features_info_,
103                targets=targets,
104                sample_weight=sample_weight,
105                current_predictions=predictions,
106            )
#

If no valid tree could be grown, stop early. Could happen due to insufficient data or no tangible gain.

107            if tree is None:
108                break
#

Apply path smoothing if specified

109            if self.path_smoothing_strength > 0.0:
110                tree.apply_smoothing(self.path_smoothing_strength)
#

Append the new tree and update predictions

111            self.trees_.append(tree)
112            predictions += self.learning_rate * tree.predict(inputs)
113
114            if self.verbose:
115                loss = -self.distribution.log_prob(y, predictions).sum()
116                print(f"Loss after tree {i + 1}: {trunc(loss)}")
#
117        self.is_fitted_ = True
118        return self
#

Make inferences using the fitted model.

  • X : pd.DataFrame
    • The input features.
  • return_type : str or None, default="predict"
    • Transformation to apply to raw predictions. Options depend on the distribution. It basically passes the raw predictions to the distribution's corresponding method. If None, returns raw predictions.
119    def predict(self, X, return_type="predict"):
120        if not self.is_fitted_:
121            raise ValueError("Model not fitted. Call fit() first.")
122
123        X = self.data_processor_.transform(X)
#

Start with the initial parameters and add contributions from each tree

124        raw_prediction = np.full(
125            (len(X), len(self.initial_params_)), self.initial_params_
126        )
127        for tree in self.trees_:
128            raw_prediction += self.learning_rate * tree.predict(X)
#

Return the desired output type. Calls the corresponding implementation in the Distribution class.

129        if return_type is not None:
130            return getattr(self.distribution, return_type)(raw_prediction)
131        return raw_prediction

4.2 Data Preprocessing

This module handles categorical feature encoding and numerical feature binning. The transformations are used both during training and inference time.

data.py

#

Data preprocessing utilities module. Defines classes and functions for handling feature information and preprocessing datasets.

1from dataclasses import dataclass
2
3import numpy as np
4import pandas as pd
5
6from .utils import map_array
#

FeatureInfo

A class to store information about a feature in the dataset.

Attributes

  • name : str
    • The name of the feature/column.
  • index : int
    • The position of the feature in the input array.
  • type : str, optional
    • The type of the feature: numerical, categorical, or category_as_numeric.
  • bins : np.ndarray, optional
    • The bin edges for numerical features or categorical features treated as numeric.
  • categories : np.ndarray, optional
    • The unique categories for categorical features.
  • target_statistics : dict, optional
    • A mapping from category to its target statistic for categorical features encoded as numeric.
 7@dataclass
 8class FeatureInfo:
 9
10    name: str
11    index: int
12    type: str = None
13    bins: np.ndarray = None
14    categories: np.ndarray = None
15    target_statistics: dict = None
#

DataPreprocessor

A data preprocessor for handling numerical and categorical features. It's used during both training and prediction.

Parameters

  • max_categories : int, default=100
    • Maximum number of unique categories for a feature to be treated as categorical. Otherwise, it is encoded as numerical using label encoding.
  • max_bins : int, default=255
    • Number of bins to use for numerical features and categorical features treated as numeric.
  • n_permutations : int, default=10
    • Number of random permutations to use for ordered target statistics encoding of categorical features.
  • seed : int, optional
    • Random seed for reproducibility.
16class DataPreprocessor:
17    def __init__(
18        self,
19        max_categories: int = 100,
20        max_bins: int = 255,
21        n_permutations: int = 10,
22        prior_strength: float = 1.0,
23        seed: int = None,
24    ):
25        self.max_categories = max_categories
26        self.max_bins = max_bins
27        self.n_permutations = n_permutations
28        self.prior_strength = prior_strength
29        self.random = np.random.default_rng(seed)
#

A list of FeatureInfo objects, one for each feature in the dataset. To be populated during the fit method.

30        self.features_info_ = None
#

Create histograms of features in the dataset. Categorical and numerical features are handled differently.

31    def fit(
32        self, X: pd.DataFrame, y: np.ndarray = None, sample_weight: np.ndarray = None
33    ) -> "DataPreprocessor":
#

Create feature info for each column

34        features_info = []
#

Identify categorical features

35        categorical_features = X.select_dtypes(
36            include=["category", "object", "string"]
37        ).columns
#

Process each feature individually

38        for index, col in enumerate(X.columns):
39            info = FeatureInfo(name=col, index=index)
40            values = None
41            category_as_numeric = False
#

Handle categorical features

42            if col in categorical_features:
#

Use pandas' categorical type to get the unique categories. NaN values are considered as a separate category (-1 code)

43                category_col = X[col].astype("category")
44                info.categories = category_col.cat.categories
#

If too many categories, use CatBoost-style target encoding

45                if len(info.categories) > self.max_categories:
46                    category_as_numeric = True
47                    assert y is not None and sample_weight is not None
48                    target_mean = np.average(y, weights=sample_weight)
#

Convert categories to codes for grouping

49                    codes = category_col.cat.codes.to_numpy()
#

Aggregate \(y * w\) and \(w\) by category. Ignore -1 (NaN) codes.

50                    valid = codes >= 0
51                    w_sum = np.bincount(
52                        codes[valid], weights=(y * sample_weight)[valid]
53                    )
54                    w_total = np.bincount(codes[valid], weights=sample_weight[valid])
#

Compute TS for category \(c\) as: $$TS(c) = \frac{\sum_{i \in c} w_i y_i + \alpha \cdot \mu}{\sum_{i \in c} w_i + \alpha}$$ where \(\mu\) is the global weighted mean of the target, and \(\alpha\) is the prior strength.

55                    info.target_statistics = dict(
56                        enumerate(
57                            (w_sum + self.prior_strength * target_mean)
58                            / (w_total + self.prior_strength)
59                        )
60                    )
#

Map the codes to target statistics for binning in the next step

61                    values = map_array(codes, info.target_statistics)
#

It's a categorical feature. No binning needed.

62                else:
63                    info.type = "categorical"
#

Bin numerical and categorical-as-numeric features

64            if col not in categorical_features or category_as_numeric:
65                if values is None:
66                    values = X[col].to_numpy()
#

Compute quantile-based bins with no interpolation

67                quantiles = np.nanquantile(
68                    values,
69                    np.linspace(0.0, 1.0, endpoint=True, num=self.max_bins + 1),
70                    method="nearest",
71                )
72                info.bins = np.unique(quantiles).astype("float64")
#

Set feature type

73                if col in categorical_features:
74                    info.type = "category_as_numeric"
75                else:
76                    info.type = "numerical"
#
77            features_info.append(info)
#
78        self.features_info_ = features_info
79        return self
#

Transform the dataset into a numerical numpy array based on the fitted feature information.

80    def transform(
81        self,
82        X: pd.DataFrame,
83        y: np.ndarray = None,
84        sample_weight: np.ndarray = None,
85        mode="test",
86    ) -> np.ndarray:
87        array = X[[info.name for info in self.features_info_]].values.copy()
88        if y is not None:
89            if isinstance(y, pd.Series):
90                y = y.to_numpy()
91            y = y.astype("float64")
92
93        for i, info in enumerate(self.features_info_):
94            if info.type == "categorical":
#

Transform categorical features to integer codes. The reason we use integer code rather than keeping original string values is that the transformed dataset is supposed to be a homogeneous float64 numpy array.

95                codes = pd.Categorical(
96                    X[info.name], categories=info.categories
97                ).codes.astype("float64")
98                codes[codes == -1.0] = np.nan
99                array[:, i] = codes
#

CatBoost-style target statistics encoding. Train and test modes differ.

100            elif info.type == "category_as_numeric":
101                category_col = pd.Categorical(X[info.name], categories=info.categories)
#

If test mode, use the precomputed target statistics mapping

102                if mode == "test":
103                    array[:, i] = map_array(category_col.codes, info.target_statistics)
#

For training mode, compute ordered target statistics averaged over multiple random permutations

104                elif mode == "train":
105                    assert y is not None and sample_weight is not None
106                    target_mean = np.average(y, weights=sample_weight)
107                    codes = category_col.codes.astype("int64")
108                    encodings = np.empty((len(X), self.n_permutations))
109                    n_cats = max(codes) + 1
#

We impose a random order on the data and for every sample \(i\), compute the target statistic using only samples that come before it in this random order. This is to avoid target leakage.

110                    for p in range(self.n_permutations):
111                        group_sum = np.zeros(n_cats)
112                        group_weight = np.zeros(n_cats)
113                        for idx in self.random.permutation(len(X)):
114                            c = codes[idx]
#

If the category is -1 (NaN), assign NaN and continue

115                            if c < 0:
116                                encodings[idx, p] = np.nan
117                                continue
#

Same formula as in fit(), but using only previous samples

118                            encodings[idx, p] = (
119                                group_sum[c] + self.prior_strength * target_mean
120                            ) / (group_weight[c] + self.prior_strength)
121                            group_sum[c] += y[idx] * sample_weight[idx]
122                            group_weight[c] += sample_weight[idx]
#

Average over all permutations

123                    array[:, i] = np.mean(encodings, axis=1)
#
124        array = array.astype("float64")
125        if y is not None:
126            return array, y
127        return array

4.3 Node and Tree Structures

Here we define the skeleton of a decision tree and its nodes. Each node stores information about split criterion, value, …, and child nodes.

The implementation is kept lean to focus more on the structure rather than optimization details.

tree.py

#
1from dataclasses import dataclass, field
2from typing import Any, Dict, List, Tuple, Union
3
4import numpy as np
#

A class representing a node in a decision tree.

Attributes

  • depth : int
    • The depth of the node in the tree.
  • sample_indices : List[int]
    • The indices of training samples that reach this node. Used during training.
  • parent : Node, optional
    • The parent node. None for the root node.
  • children : Dict[str, Node]
    • The child nodes, typically with keys "left" and "right".
  • gradient_sum : np.ndarray
    • The sum of gradients for samples in this node.
  • hessian_sum : np.ndarray
    • The sum of hessians for samples in this node.
  • l1_regularization : float
    • The L1 regularization term.
  • l2_regularization : float
    • The L2 regularization term.
  • feature : str, optional
    • Feature name used for splitting at this node.
  • feature_index : int, optional
    • Index of the feature in the input array.
  • split_point : Union[float, Tuple], optional
    • The split point for numerical features or a tuple of categories for categorical features.
  • nulls_to_left : bool, optional
    • Whether null values go to the left child.
  • smoothed_value : np.ndarray, optional
    • The smoothed value for the node, used for prediction. Only set for leaf nodes.
  • info : Dict[str, Any]
    • Additional information about the node.
 5@dataclass
 6class Node:
 7
 8    depth: int
 9    sample_indices: List[int] = field(default_factory=list)
10    parent: "Node" = None
11    children: Dict[str, "Node"] = field(default_factory=dict)
12    gradient_sum: np.ndarray = None
13    hessian_sum: np.ndarray = None
14    l1_regularization: float = 0.0
15    l2_regularization: float = 0.0
16    feature: str = None
17    feature_index: int = None
18    split_point: Union[float, Tuple] = None
19    nulls_to_left: bool = None
20    smoothed_value: np.ndarray = None
21    info: Dict[str, Any] = field(default_factory=dict)
#

Calculate the leaf value using the formula: $$ \text{Value} = - \frac{\text{sign}(G) \cdot \max(|G| - \lambda_{\text{L1}}, 0)}{H + \lambda_{\text{L2}}} $$

22    def value(self, smooth: bool = True) -> float:
23        if smooth and self.smoothed_value is not None:
24            return self.smoothed_value
25
26        gradient = self.gradient_sum
27        if self.l1_regularization:
28            gradient = np.sign(gradient) * np.maximum(
29                np.abs(gradient) - self.l1_regularization, 0.0
30            )
31        return -gradient / (self.hessian_sum + self.l2_regularization + 1e-16)
#

Returns the type of the node: InternalNode, Leaf, or VirtualNode. VirtualNode is a special node used only during training to represent nodes that have not been instantiated yet.

32    @property
33    def type(self) -> str:
34        if self.children:
35            return "InternalNode"
36        elif self.gradient_sum is not None and self.hessian_sum is not None:
37            return "Leaf"
38        else:
39            return "VirtualNode"
#

Returns a boolean mask indicating which samples go to the left child.

Parameters

  • array : np.ndarray
    • The input feature array.
  • input_type : str, default="all"
    • Specifies whether the input array contains all features ("all") or just the feature used for splitting ("feature").
40    def criterion(self, array: np.ndarray, input_type: str = "all") -> np.ndarray:
41        if input_type == "all":
42            array = array[:, self.feature_index]
43        null_mask = np.isnan(array) & self.nulls_to_left
44        if isinstance(self.split_point, tuple):
45            return null_mask | np.isin(array, self.split_point[0])
46        else:
47            return null_mask | (array <= self.split_point)
#

String representation of the node. Used for visualization and debugging.

48    def __repr__(self):
49        if self.children:
50            return f"{self.type}(feature='{self.feature}', split_point={self.split_point}, samples={len(self.sample_indices)})"
51        elif self.gradient_sum is not None and self.hessian_sum is not None:
52            return f"{self.type}(value={self.value().round(decimals=4)}, samples={len(self.sample_indices)})"
53        else:
54            return f"{self.type}(samples={len(self.sample_indices)})"
#

Helper method to update a dataclass's fields.

55    def update(self, **kwargs):
56        for key, value in kwargs.items():
57            if not hasattr(self, key):
58                raise AttributeError(f"Node has no attribute '{key}'")
59            setattr(self, key, value)
#

A structure representing a decision tree.

60class Tree:
61    def __init__(self, root: Node = None):
62        self.root = root
#

Make predictions for the input samples x starting from the given node (or root if None). We traverse the tree from the root to the leaves based on the split criteria at each node, and aggregate the leaf values to produce the final predictions.

Parameters

  • x : np.ndarray
    • The input samples for which predictions are to be made, with shape (n_samples, n_features).
  • node : Node, optional
    • The current node in the tree from which to start predictions. If None, starts from the root node.

Returns

  • output : np.ndarray
    • The leaf values for each input sample, with shape (n_samples, n_outputs).
63    def predict(self, x: np.ndarray, node: Node = None):
64        node = node or self.root
65        n_samples = len(x)
#

If the node is an internal node, split the samples and recurse

66        if node.children:
67            mask = node.criterion(x)
68            n_output = len(node.children["left"].value())
69            output = np.zeros((n_samples, n_output))
70            output[mask] = self.predict(x[mask], node.children["left"])
71            output[~mask] = self.predict(x[~mask], node.children["right"])
#

If in the leaf node, return the leaf value for all samples

72        else:
73            output = np.tile(node.value(), (n_samples, 1))
74        return output
#

Returns the number of leaves in the tree.

75    def __len__(self):
76        return len(self.leaves)
#

Iterator to traverse all nodes in the tree using depth-first search.

77    def __iter__(self):
#

Utility for traversal of the tree. Since it's a recursive generator, we need to use yield instead of return to yield nodes one by one. On a similar note, yield from is used for calling the generator recursively. It's a rarely used syntax but I find it a neat feature of Python :)

78        def dfs(node: Node):
79            yield node
80            for child in node.children.values():
81                yield from dfs(child)
82
83        if self.root:
84            yield from dfs(self.root)
#

Returns a list of all leaf nodes in the tree. We use the iter method to traverse the tree.

85    @property
86    def leaves(self) -> List[Node]:
87        return [node for node in self if node.type == "Leaf"]
#

Apply exponential path smoothing to all leaf values (in-place).

Blends each leaf with ancestors using exponential decay: leaf gets weight 1, parent gets \(\beta\), grandparent gets \(\beta^2\), etc.

$$v_{\text{smoothed}} = \frac{\sum_{i=0}^{d} \beta^{d-i} \cdot v_i}{\sum_{i=0}^{d} \beta^{d-i}}$$

Parameters

  • beta : float in (0, 1], default=0.5
    • Decay factor. Lower values = stronger regularization toward shallow predictions.
88    def apply_smoothing(self, beta: float):
#
89        def dfs(node: Node, weighted_sum: np.ndarray, weight_total: float):
#

Add current node's contribution

90            weighted_sum = weighted_sum + node.value(smooth=False)
91            weight_total = weight_total + 1.0
92
93            if node.type == "Leaf":
94                node.smoothed_value = weighted_sum / weight_total
#

Discount contributions from ancestors and recurse

95            else:
96                weighted_sum = weighted_sum * beta
97                weight_total = weight_total * beta
98                for child in node.children.values():
99                    dfs(child, weighted_sum, weight_total)
#
100        initial_sum = np.zeros_like(self.root.value(smooth=False))
101        dfs(self.root, initial_sum, 0.0)
#

Print the tree structure in a readable format.

102    def print(self, node=None, level=0, prefix="Root: "):
103        node = node or self.root
104        print(" " * (level * 4) + prefix + str(node))
105        if node.children:
106            self.print(node.children.get("left"), level + 1, prefix="L--- ")
107            self.print(node.children.get("right"), level + 1, prefix="R--- ")

4.4 Tree Optimization

This module implements the core logic for creating decision trees used in Gradient Boosted Trees. The class TreeGrower is responsible for growing the tree by finding the best splits based on the gradients and hessians. I stole the name “TreeGrower” from Sklearn’s implementation, but not sure if they were the first.

The flow of the algorithm is as follows:

  1. Subsample the data if specified. This is to introduce randomness and prevent overfitting. Training on different subsets of sample and features results in a more diverse set of trees.
  2. Initialize the root node.
  3. Use a priority queue to keep track of all node candidates to be split, and prioritize them based on their potential to reduce loss.
  4. Iteratively:
    • Evaluate the best split and gain for the unprocessed nodes, and update the priority queue.
    • Select the node with the highest gain from the priority queue to split. Update its information, and create its child nodes to be processed in the next iteration.
    • Stop when the maximum number of leaves is reached, or no more beneficial splits are found.

This is called leaf-wise growth, as opposed to level-wise growth in traditional XGBoost, and also CatBoost since it uses oblivious trees (as far as I know).

grower.py

#
 1from dataclasses import dataclass
 2from queue import PriorityQueue
 3from typing import List, Tuple, Union
 4
 5import numpy as np
 6
 7from .data import FeatureInfo
 8from .tree import Node, Tree
 9from .distributions import Distribution
10from .utils import groupby_sum_2d
#

SplitCandidate

A class to store information about a potential node split during tree growth.

Attributes

  • gain : float
    • The gain achieved by this split.
  • feature : str
    • The feature on which to split.
  • feature_index : int
    • The index of the feature in the input array.
  • split_point : Union[float, Tuple]
    • For numerical features, the threshold value. For categorical features, a tuple of two arrays representing the left and right category groups.
  • nulls_to_left : bool
    • Whether null values go to the left child.
  • gradient_sum : np.ndarray
    • The sum of gradients for samples in the node.
  • hessian_sum : np.ndarray
    • The sum of hessians for samples in the node.
  • left_grad_sum : np.ndarray
    • The sum of gradients for samples going to the left child.
  • left_hess_sum : np.ndarray
    • The sum of hessians for samples going to the left child.
11@dataclass
12class SplitCandidate:
13
14    gain: float
15    feature: str = None
16    feature_index: int = None
17    split_point: Union[float, Tuple] = None
18    nulls_to_left: bool = None
19    gradient_sum: np.ndarray = None
20    hessian_sum: np.ndarray = None
21    left_grad_sum: np.ndarray = None
22    left_hess_sum: np.ndarray = None
#
23    @property
24    def right_grad_sum(self) -> np.ndarray:
25        return self.gradient_sum - self.left_grad_sum
26
27    @property
28    def right_hess_sum(self) -> np.ndarray:
29        return self.hessian_sum - self.left_hess_sum
#

TreeGrower

A class to grow decision trees. The core logic for finding the best splits and constructing the tree structure is implemented here.

Parameters

  • distribution : Distribution
    • The objective function defining the loss and gradient/hessian computations.
  • learning_rate : float
    • The learning rate for boosting.
  • max_leaves : int
    • The maximum number of leaves in the tree.
  • max_depth : int
    • The maximum depth of the tree.
  • min_samples_split : int
    • The minimum number of samples required to split a node.
  • min_gain_to_split : float
    • The minimum gain required to perform a split.
  • l1_regularization : float
    • The L1 regularization term for leaf value calculation.
  • l2_regularization : float
    • The L2 regularization term for leaf value calculation.
  • min_weight_leaf : float
    • The minimum sum of instance weights required in a leaf node.
  • feature_fraction : float
    • The fraction of features to consider when looking for the best split.
  • samples_fraction : float
    • The fraction of samples to consider when growing the tree.
  • goss_top_rate : float
    • The top rate for Gradient-based One-Side Sampling (GOSS).
  • goss_bottom_rate : float
    • The bottom rate for GOSS.
  • goss_rescale_bottom : bool
    • Whether to rescale the bottom samples in GOSS.
  • objective_weight : List[float]
    • Weights for multi-output objectives.
  • n_workers : int
    • The number of parallel workers to use for finding splits.
  • seed : int
    • Random seed for reproducibility.
30@dataclass
31class TreeGrower:
32
33    distribution: Distribution
34    learning_rate: float
35    max_leaves: int
36    max_depth: int = 100
37    min_samples_split: int = 2
38    min_gain_to_split: float = 0.0
39    l1_regularization: float = 0.0
40    l2_regularization: float = 0.0
41    min_weight_leaf: float = float("-inf")
42    feature_fraction: float = 1.0
43    samples_fraction: float = 1.0
44    goss_top_rate: float = None
45    goss_bottom_rate: float = None
46    goss_rescale_bottom: bool = False
47    objective_weight: List[float] = None
48    n_workers: int = None
49    seed: int = None
#

Initialize the random state for rng operations

50    def __post_init__(self):
51        self.random = np.random.default_rng(self.seed)
#

Train a decision tree using the provided dataset.

Parameters

  • inputs : np.ndarray
    • The input feature array.
  • features_info : List[FeatureInfo]
    • List of FeatureInfo objects describing each feature.
  • targets : np.ndarray
    • The target values.
  • sample_weight : np.ndarray
    • Sample weights for each instance.
  • current_predictions : np.ndarray
    • The current predictions from the ensemble. The goal of adding a new tree is to correct these predictions.
52    def grow(
53        self,
54        inputs: np.ndarray,
55        features_info: List["FeatureInfo"],
56        targets: np.ndarray,
57        sample_weight: np.ndarray,
58        current_predictions: np.ndarray,
59    ) -> Tree:
#

Subsample features and samples if required

60        inputs, features_info, targets, sample_weight, current_predictions = (
61            self.subsample_dataset(
62                inputs,
63                features_info,
64                targets,
65                sample_weight,
66                current_predictions,
67            )
68        )
#

Default sample weights to 1 if not provided

69        if sample_weight is None:
70            sample_weight = np.ones(len(inputs), dtype=np.float64)
#

Compute gradients and hessians for the samples in the node

71        gradient, hessian = self.distribution.gradient_hessian(
72            targets,
73            current_predictions,
74            sample_weight,
75        )
#

NOTE: I don't have a scientific justification for this clipping, but I wanted to avoid having division by zero errors during gain calculation, and I also saw XGBoost do something similar. Will have to revisit this later.

76        hessian = np.maximum(hessian, 1e-6)
#

GOSS Sampling

77        if self.goss_top_rate is not None and self.goss_bottom_rate is not None:
78            (
79                gradient,
80                hessian,
81                inputs,
82                targets,
83                sample_weight,
84            ) = self.apply_goss_sampling(
85                gradient, hessian, inputs, targets, sample_weight
86            )
#

Initialize the tree with a root node

87        root = Node(
88            depth=0,
89            l2_regularization=self.l2_regularization,
90            sample_indices=np.arange(len(inputs)),
91        )
92        tree = Tree(root=root)
#

Priority queue to store split candidates. Higher gain splits have higher priority.

93        candidates = PriorityQueue()
#

Start growing the tree

94        leaves_to_process = [root]
95        n_processed = 0
96        for _ in range(self.max_leaves):
97            for node in leaves_to_process:
#

Check if node can be split

 98                if (
 99                    node.depth >= self.max_depth
100                    or len(node.sample_indices) < self.min_samples_split
101                ):
102                    continue
#

Find the best split for the given node

103                split_candidate = self.find_best_split(
104                    inputs[node.sample_indices],
105                    features_info,
106                    gradient[node.sample_indices],
107                    hessian[node.sample_indices],
108                    sample_weight[node.sample_indices],
109                )
#

Add the split proposal to the queue if it satisfies min gain

110                if (split_candidate is not None) and (
111                    split_candidate.gain > self.min_gain_to_split
112                ):
#

The queue stores tuples of the form (-gain, node_index, node, split_candidate) since PriorityQueue in Python sorts in ascending order.

113                    candidates.put(
114                        (
115                            -split_candidate.gain,
116                            n_processed,  # tie-breaker
117                            node,
118                            split_candidate,
119                        )
120                    )
#
121                n_processed += 1
#
122            leaves_to_process = []
123            if candidates.empty():
124                break
#

Get the global best split candidate

125            _, _, node, split_info = candidates.get()
126            self.split_node(node, inputs, features_info, split_info)
#

Add children to the list for processing in the next iteration

127            leaves_to_process.extend(node.children.values())
#
128        if len(tree) == 0:
129            print("No splits were made; returning None")
130            return None
131        return tree
#

Find the best split for the given node. This is a helper method that can evaluate each feature in parallel and aggregate the results.

132    def find_best_split(
133        self, inputs, features_info, gradient, hessian, sample_weight
134    ) -> SplitCandidate:
135        tasks = [
136            (
137                info,
138                inputs[:, index],
139                gradient,
140                hessian,
141                sample_weight,
142            )
143            for index, info in enumerate(features_info)
144        ]
#

Parallelize feature processing if n_workers > 1. Otherwise, process sequentially.

145        if self.n_workers is not None and self.n_workers > 1:
146            from concurrent.futures import ThreadPoolExecutor
147
148            with ThreadPoolExecutor(max_workers=self.n_workers) as executor:
149                feature_results = list(
150                    executor.map(lambda t: self._process_feature(*t), tasks)
151                )
152        else:
153            feature_results = [self._process_feature(*task) for task in tasks]
#

Return the best result

154        return max(
155            (r for r in feature_results if r is not None),
156            key=lambda r: r.gain,
157            default=None,
158        )
#

Find the best split for a given feature. This part is the backbone of the optimization.

159    def _process_feature(
160        self,
161        info: "FeatureInfo",
162        values: np.ndarray,
163        gradient: np.ndarray,
164        hessian: np.ndarray,
165        sample_weight: np.ndarray,
166    ):
#

Handle categorical and numerical features differently

167        if info.type == "categorical":
#

Calculate group-wise sums of gradients and hessians for each category

168            cats, cat_indices = np.unique(values, return_inverse=True)
169            groups = cats
170            grad_group, hess_group, weight_group = groupby_sum_2d(
171                n_groups=len(groups),
172                group_indices=cat_indices,
173                gradients=gradient,
174                hessians=hessian,
175                sample_weight=sample_weight,
176            )
#

Sort categories by gain to convert categorical split into a ordered split problem: categories[:k] vs categories[k:].

177            fisher_order = self.calculate_gain(grad_group, hess_group)
178            sort_indices = np.argsort(fisher_order)
#

Reorder arrays based on the calculated order

179            groups, grad_group, hess_group, weight_group = (
180                groups[sort_indices],
181                grad_group[sort_indices],
182                hess_group[sort_indices],
183                weight_group[sort_indices],
184            )
#
185        else:
#

For numerical features, bin the values first and then compute group-wise sums

186            bins = info.bins
187            bin_indices = np.digitize(values, bins, right=True)
188            bin_indices[np.isnan(values)] = len(bins)
189            groups = np.concatenate([bins, [np.nan]])
190
191            grad_group, hess_group, weight_group = groupby_sum_2d(
192                n_groups=len(groups),
193                group_indices=bin_indices,
194                gradients=gradient,
195                hessians=hessian,
196                sample_weight=sample_weight,
197            )
#

Separate out the null group

198        null_group = np.isnan(groups)
199        grad_null_sum = grad_group[null_group].sum(axis=0)
200        hess_null_sum = hess_group[null_group].sum(axis=0)
201        weight_null_sum = weight_group[null_group].sum(axis=0)
#

Calculate cumulative sums excluding the null group

202        groups = groups[~null_group]
203        grad_group_csum = np.cumsum(grad_group[~null_group], axis=0)
204        hess_group_csum = np.cumsum(hess_group[~null_group], axis=0)
205        weight_group_csum = np.cumsum(weight_group[~null_group], axis=0)
206
207        if len(groups) <= 1:
208            return None
#

Node total sums

209        node_grad_sum = grad_group_csum[-1] + grad_null_sum
210        node_hess_sum = hess_group_csum[-1] + hess_null_sum
211        node_weight_sum = weight_group_csum[-1] + weight_null_sum
#

Calculate split gains for every possible split point and null direction

212        grad_group_csum = grad_group_csum[:-1]
213        hess_group_csum = hess_group_csum[:-1]
214        weight_group_csum = weight_group_csum[:-1]
215
216        parent_gain = self.calculate_gain(node_grad_sum, node_hess_sum)
217        gains_with_nulls_left = (
218            self.calculate_gain(
219                grad_group_csum + grad_null_sum,
220                hess_group_csum + hess_null_sum,
221            )
222            + self.calculate_gain(
223                node_grad_sum - (grad_group_csum + grad_null_sum),
224                node_hess_sum - (hess_group_csum + hess_null_sum),
225            )
226            - parent_gain
227        )
228        gains_with_nulls_right = (
229            self.calculate_gain(
230                grad_group_csum,
231                hess_group_csum,
232            )
233            + self.calculate_gain(
234                node_grad_sum - grad_group_csum,
235                node_hess_sum - hess_group_csum,
236            )
237            - parent_gain
238        )
#

Determine the best split for this feature

239        split_gain_combined = np.concatenate(
240            [gains_with_nulls_left, gains_with_nulls_right]
241        )
#

Enforce minimum weight per leaf constraint

242        valid_null_left = (
243            weight_group_csum + weight_null_sum >= self.min_weight_leaf
244        ) & (
245            node_weight_sum - (weight_group_csum + weight_null_sum)
246            >= self.min_weight_leaf
247        )
248        valid_null_right = (weight_group_csum >= self.min_weight_leaf) & (
249            node_weight_sum - weight_group_csum >= self.min_weight_leaf
250        )
251        split_gain_combined[~np.concatenate([valid_null_left, valid_null_right])] = (
252            -np.inf
253        )
#

Find the overall best split and store the details in a SplitCandidate object

254        best_gain_idx = np.argmax(split_gain_combined)
255        feature_gain = split_gain_combined[best_gain_idx]
256
257        nulls_to_left = True if best_gain_idx < (len(groups) - 1) else False
258        split_idx = best_gain_idx % (len(groups) - 1)
259
260        left_grad_sum = grad_group_csum[split_idx]
261        left_hess_sum = hess_group_csum[split_idx]
262        if nulls_to_left:
263            left_grad_sum += grad_null_sum
264            left_hess_sum += hess_null_sum
265
266        if info.type == "categorical":
267            split_point = (
268                groups[: split_idx + 1],
269                groups[split_idx + 1 :],
270            )
271        else:
272            split_point = groups[split_idx]
273
274        return SplitCandidate(
275            gain=feature_gain,
276            feature=info.name,
277            feature_index=info.index,
278            split_point=split_point,
279            nulls_to_left=nulls_to_left,
280            gradient_sum=node_grad_sum,
281            hessian_sum=node_hess_sum,
282            left_grad_sum=left_grad_sum,
283            left_hess_sum=left_hess_sum,
284        )
#

Split the given node using the provided split information. Creates left and right child nodes and updates the parent node accordingly.

285    def split_node(
286        self,
287        node: Node,
288        inputs: np.ndarray,
289        features_info: List["FeatureInfo"],
290        split_info: SplitCandidate,
291    ):
#

Update the split criteria for the parent node

292        node.update(
293            feature=split_info.feature,
294            feature_index=split_info.feature_index,
295            split_point=split_info.split_point,
296            nulls_to_left=split_info.nulls_to_left,
297            gradient_sum=split_info.gradient_sum,
298            hessian_sum=split_info.hessian_sum,
299        )
#

Determine the feature index in the subsampled dataset

300        feature_index = next(
301            i for i, f in enumerate(features_info) if f.name == split_info.feature
302        )
#

Find out which samples go to the left and right child nodes. This information is used later for further splits.

303        mask = node.criterion(
304            inputs[node.sample_indices, feature_index], input_type="feature"
305        )
306        left_child = Node(
307            parent=node,
308            depth=node.depth + 1,
309            l2_regularization=node.l2_regularization,
310            sample_indices=node.sample_indices[mask],
311            gradient_sum=split_info.left_grad_sum,
312            hessian_sum=split_info.left_hess_sum,
313        )
314        right_child = Node(
315            parent=node,
316            depth=node.depth + 1,
317            l2_regularization=node.l2_regularization,
318            sample_indices=node.sample_indices[~mask],
319            gradient_sum=split_info.right_grad_sum,
320            hessian_sum=split_info.right_hess_sum,
321        )
322        node.children["left"] = left_child
323        node.children["right"] = right_child
#

Calculate the per-node gain based on gradients and hessians. The gain is calculated as:

$$\text{gain} = \frac{(T(G))^2}{H + \lambda}$$

where:

  • \(T(G) = \text{sign}(G) \cdot \max(0, |G| - \alpha)\) is the soft-thresholding operator
  • \(G\) is the sum of gradients
  • \(H\) is the sum of hessians
  • \(\alpha\) is the L1 regularization parameter (induces sparsity)
  • \(\lambda\) is the L2 regularization parameter (prevents overfitting)

Parameters

  • gradients : np.ndarray
    • The sum of gradients for the node(s) with shape (n_nodes, n_outputs).
  • hessians : np.ndarray
    • The sum of hessians for the node(s) with shape (n_nodes, n_outputs). Returns
  • gain_outputs : np.ndarray
    • The calculated gain for each node, shape (n_nodes,).
324    def calculate_gain(self, gradients, hessians):
325        if self.l1_regularization > 0:
326            gradients = np.sign(gradients) * np.maximum(
327                0, np.abs(gradients) - self.l1_regularization
328            )
329        gain_outputs = (gradients**2) / (hessians + self.l2_regularization + 1e-16)
330        if self.objective_weight is not None:
331            gain_outputs *= self.objective_weight / np.sum(self.objective_weight)
332        return gain_outputs.sum(axis=-1)
#

Subsample features and samples based on the specified fractions. This is useful for creating a variety of trees in the ensemble and preventing overfitting.

333    def subsample_dataset(
334        self,
335        inputs: np.ndarray,
336        features_info: List["FeatureInfo"],
337        targets: np.ndarray,
338        sample_weight: np.ndarray,
339        current_predictions: np.ndarray,
340    ) -> Tuple[np.ndarray]:
#

Take a random subset of features if specified

341        if self.feature_fraction < 1:
342            n_features = inputs.shape[1]
343            n_subsample_features = int(n_features * self.feature_fraction)
344            feature_indices = self.random.choice(
345                n_features, size=n_subsample_features, replace=False
346            )
347            inputs = inputs[:, feature_indices]
348            features_info = [features_info[i] for i in feature_indices]
#

Subsample data points if specified

349        if self.samples_fraction < 1:
350            n_samples = inputs.shape[0]
351            subsample_size = int(n_samples * self.samples_fraction)
352            subsample_indices = self.random.choice(
353                n_samples, size=subsample_size, replace=False
354            )
355            inputs = inputs[subsample_indices]
356            targets = targets[subsample_indices]
357            if sample_weight is not None:
358                sample_weight = sample_weight[subsample_indices]
359            current_predictions = current_predictions[subsample_indices]
360
361        return (
362            inputs,
363            features_info,
364            targets,
365            sample_weight,
366            current_predictions,
367        )
#

Apply Gradient-based One-Side Sampling. The idea is to retain instances with large gradients while randomly sampling from instances with small gradients. This helps focus the model on hard-to-predict instances while still maintaining a representative sample of the overall data.

Input: \(g\) (gradients), \(h\) (hessians), \(X\) (inputs), \(y\) (targets), \(w\) (sample weights), \(a\) (top rate), \(b\) (bottom rate), \(\text{rescale}\) (rescale-bottom flag)

$$ \begin{aligned} & n = |g|,\ n_{\text{top}} = \lfloor a n \rfloor,\ n_{\text{bot}} = \lfloor b n \rfloor \\ & r_i = \lVert g_i \rVert_1,\ \pi = \operatorname{argsort}(r;\ \text{descending}) \\ & T = \{\pi_1,\dots,\pi_{n_{\text{top}}}\},\ C = \{\pi_{n_{\text{top}}+1},\dots,\pi_n\} \\ & B \sim \text{UniformSubset}(C,\ n_{\text{bot}}),\ S = T \cup B \\ & \text{if rescale:} \\ &\quad s = \frac{\sum_{i \notin T} w_i}{\sum_{i \in B} w_i},\ \forall i \in B:\ (g_i,h_i,w_i) \leftarrow s (g_i,h_i,w_i) \end{aligned} $$

Output: \( \{(x_i,y_i,g_i,h_i,w_i)\}_{i \in S} \)

368    def apply_goss_sampling(self, gradient, hessian, inputs, targets, sample_weight):
369        n_samples = len(gradient)
370        n_top = int(n_samples * self.goss_top_rate)
371        n_bottom = int(n_samples * self.goss_bottom_rate)
#

Sort the samples by absolute gradient values in descending order

372        abs_grad = np.abs(gradient).sum(axis=1)
373        sorted_indices = np.argsort(-abs_grad)
#

Select top and bottom samples

374        top_indices = sorted_indices[:n_top]
375        bottom_indices = self.random.choice(
376            sorted_indices[n_top:], n_bottom, replace=False
377        )
378        selected_indices = np.concatenate([top_indices, bottom_indices])
#

I added an argument to make it optional whether to rescale the bottom instances or not. I found that in some cases, not rescaling gives better results.

379        scale = 1.0
380        if self.goss_rescale_bottom:
381            scale = (
382                np.sum(sample_weight) - np.sum(sample_weight[top_indices])
383            ) / np.sum(sample_weight[bottom_indices])
384
385        gradient = gradient[selected_indices]
386        hessian = hessian[selected_indices]
387        sample_weight = sample_weight[selected_indices]
388
389        gradient[n_top:] *= scale
390        hessian[n_top:] *= scale
391        sample_weight[n_top:] *= scale
392
393        return (
394            gradient,
395            hessian,
396            inputs[selected_indices],
397            targets[selected_indices],
398            sample_weight,
399        )

4.5 Loss Functions and Distributions

This part took a while to get right, but I had a lot of inspiration from xgboost-distribution, torch.distributions which helped in the design.

Here, I take the probabilistic approach by using Maximum Likelihood Estimation (MLE) to introduce the two loss functions (Squared and BCE) that I implemented here, but in reality as long as you can compute the gradients and hessians for a given loss function, you can plug it in. The reason I like the probabilistic approach is that it opens the door to more advanced use-cases such as uncertainty estimation (variance parameter), and also gives an intuitive understanding behind the loss functions we use but rarely question.

distributions.py

#
1from abc import ABC, abstractmethod
2from typing import Tuple
3
4import numpy as np
5
6from .utils import sigmoid, to_2d
#

Base class for loss distributions.

7class Distribution(ABC):
#

Number of parameters/output dimensions required by the distribution.

 8    @property
 9    @abstractmethod
10    def n_outputs(self) -> int:
#

Compute the log probability of the true values given the predictions.

11    @abstractmethod
12    def log_prob(self, y_true: np.ndarray, y_pred: np.ndarray) -> np.ndarray:
#

Return interpretable predictions (e.g., [mu, sigma] for Gaussian, [prob] for Bernoulli).

13    @abstractmethod
14    def predict(self, y_pred: np.ndarray) -> np.ndarray:
#

Compute the gradient and hessian of the loss function w.r.t. predictions.

15    @abstractmethod
16    def gradient_hessian(
17        self, y_true: np.ndarray, y_pred: np.ndarray, weight: np.ndarray = None
18    ) -> Tuple[np.ndarray, np.ndarray]:
#

Initialize the parameters based on the target values.

19    @abstractmethod
20    def init_params(self, y: np.ndarray) -> np.ndarray:
#

Generate samples from the distribution given predictions.

21    @abstractmethod
22    def sample(
23        self, y_pred: np.ndarray, n_samples: int, random_state: np.random.RandomState
24    ) -> np.ndarray:
#

Gaussian distribution objective for regression tasks. Uses natural parameterization for faster convergence.

Parameters

  • learn_variance : bool, default=False
    • Whether to learn the variance parameter or assume it is fixed. If False: equivalent to Squared loss (homoscedastic regression). If True: models both mean and variance (heteroscedastic regression).
25class Gaussian(Distribution):
26    def __init__(self, learn_variance: bool = False):
27        self.learn_variance = learn_variance
28        if not learn_variance:
29            self.eta2_fixed = -0.5
#
30    @property
31    def n_outputs(self) -> int:
32        return 2 if self.learn_variance else 1
#

Log probability of Gaussian distribution. Meaning, for each data point, we calculate \(\log P(y_{\text{true}} \mid \theta)\) where \(\theta\) are the parameters predicted by the model. During learning, we find the optimal \(\theta\) that maximizes this log probability over the training set.

This implementation uses the natural parameterization of the Gaussian distribution, where the learnable parameters are:

$$\begin{aligned} \eta_1 &= \frac{\mu}{\sigma^2} \\ \eta_2 &= -\frac{1}{2\sigma^2} \end{aligned}$$

In practice, we don't learn \(\eta_2\) directly, since it must be negative, but the model output is unbounded. Instead, we model \(z\) where \(\eta_2 = -\exp(z)\). This ensures \(\eta_2\) is always negative, since \(\exp(z) > 0\) for all real \(z\).

33    def log_prob(self, y_true: np.ndarray, y_pred: np.ndarray) -> np.ndarray:
#

Convert the raw predictions (\(\eta_1, z\)) to (\(\mu, \sigma\))

34        mu, sigma = self._format_prediction(y_pred).T
#

Compute log probability using the standard Gaussian formula

35        log_prob = (
36            -0.5 * np.log(2 * np.pi)
37            - np.log(sigma)
38            - 0.5 * ((y_true - mu) ** 2) / (sigma**2)
39        )
40        return log_prob
#

Return predictions \((\mu, \sigma)\). Output Shape: (n_samples, 1 or 2) depending on whether variance is learnable.

41    def predict(self, y_pred: np.ndarray) -> np.ndarray:
42        return self._format_prediction(y_pred)[:, : self.n_outputs]
#

Compute the gradient and hessian of the negative log likelihood loss w.r.t. the natural parameters \((\eta_1, \eta_2)\).

43    def gradient_hessian(
44        self, y_true: np.ndarray, y_pred: np.ndarray, weight: np.ndarray = None
45    ) -> Tuple[np.ndarray, np.ndarray]:
46        eta1, eta2 = self._format_prediction(y_pred, natural=True).T
47
48        grad = np.zeros_like(y_pred)
49        hess = np.zeros_like(grad)
#

Derivatives w.r.t. \(\eta_1\)

50        grad[:, 0] = -y_true - eta1 / (2 * eta2)
51        hess[:, 0] = -1 / (2 * eta2)
#

If learning variance, then \(z\) is also a learnable parameter

52        if self.learn_variance:
#

Derivatives w.r.t. \(\eta_2\)

53            grad_eta2 = -(y_true**2) + (eta1**2 / (4 * eta2**2)) - 1 / (2 * eta2)
54            hess_eta2 = -(eta1**2) / (2 * eta2**3) + 1 / (2 * eta2**2)
#

Derivatives w.r.t \(z\), which is the raw output of the model Chain rule: \(\frac{dL}{dz} = \frac{dL}{d\eta_2} \cdot \frac{d\eta_2}{dz}\) where \(\frac{d\eta_2}{dz} = -\exp(z) = \eta_2\)

55            grad[:, 1] = grad_eta2 * eta2
56            hess[:, 1] = hess_eta2 * (eta2**2) + grad_eta2 * eta2
#
57        if weight is not None:
58            weight = to_2d(weight)
59            grad *= weight
60            hess *= weight
61
62        return grad, hess
#

Returns initial \((\eta_1, \eta_2)\) or \((\eta_1)\) if variance is fixed.

63    def init_params(self, y):
64        mu = np.mean(y)
65        if self.learn_variance:
66            sigma = np.std(y)
67            eta1, eta2 = self.to_natural(mu, sigma)
68            z = np.log(-eta2)  # Inverse of eta2 = -exp(z)
69            return np.array([eta1, z])
70        return np.array([mu])
#

Mean is \(\mu\) parameter of the Gaussian.

71    def mean(self, y_pred: np.ndarray) -> np.ndarray:
72        mu, _ = self._format_prediction(y_pred).T
73        return mu
#

Standard deviation is \(\sigma\) parameter of the Gaussian.

74    def stdev(self, y_pred: np.ndarray) -> np.ndarray:
75        _, sigma = self._format_prediction(y_pred).T
76        return sigma
#

Generate samples from the Gaussian distribution given predictions.

77    def sample(
78        self, y_pred, n_samples: int, random_state: np.random.RandomState
79    ) -> np.ndarray:
80        mu, sigma = self._format_prediction(y_pred).T
81        return random_state.normal(mu, sigma, size=(mu.shape[0], n_samples))
#

Compute the entropy of the Gaussian distribution given predictions.

82    def entropy(self, y_pred: np.ndarray) -> np.ndarray:
83        _, sigma = self._format_prediction(y_pred).T
84        return 0.5 * np.log(2 * np.pi * np.e * sigma**2)
#

Convert raw predictions to \((\mu, \sigma)\) or \((\eta_1, \eta_2)\).

85    def _format_prediction(
86        self, y_pred: np.ndarray, natural: bool = False
87    ) -> np.ndarray:
88        eta1 = y_pred[:, 0]
89        if self.learn_variance:
90            z = y_pred[:, 1]
#

model \(z\) instead of \(\eta_2\) directly to ensure negativity

91            eta2 = -np.exp(z)
#
92        else:
93            eta2 = np.full_like(eta1, self.eta2_fixed)
94
95        if natural:
96            return np.column_stack([eta1, eta2])
97        mu, sigma = self.from_natural(eta1, eta2)
98        return np.column_stack([mu, sigma])
#

Helper function to convert \((\mu, \sigma)\) to \((\eta_1, \eta_2)\).

 99    @staticmethod
100    def to_natural(mu, sigma):
101        eta1 = mu / sigma**2
102        eta2 = -1 / (2 * sigma**2)
103        return eta1, eta2
#

Helper function to convert \((\eta_1, \eta_2)\) to \((\mu, \sigma)\).

104    @staticmethod
105    def from_natural(eta1, eta2):
106        mu = -eta1 / (2 * eta2)
107        sigma = np.sqrt(-1 / (2 * eta2))
108        return mu, sigma
#

Logistic objective for binary classification tasks.

109class Bernoulli(Distribution):
#
110    @property
111    def n_outputs(self) -> int:
112        return 1
#

Log probability of Bernoulli distribution.

The Bernoulli distribution is: $$P(y \mid p) = p^y (1-p)^{1-y}$$

Where \(p\) is the probability of success, and \(y \in \{0, 1\}\). Taking the log, we get: $$\log P(y \mid p) = y \log p + (1-y) \log(1-p)$$

Which is the standard binary cross-entropy loss.

Logit Parameterization:

We model \(z \in \mathbb{R}\) (logit) instead of \(p\) directly, using the sigmoid transform: $$p = \sigma(z) = \frac{1}{1 + e^{-z}}$$

The rationale behind this is that since the model outputs are unbounded, using sigmoid squashes them into the valid probability range (0, 1).

By substituting \(p = \sigma(z)\) into the log probability, we get: $$\log P(y \mid z) = y \cdot z - \log(1 + e^{z})$$

113    def log_prob(self, y_true: np.ndarray, y_pred: np.ndarray) -> np.ndarray:
114        logit = y_pred[:, 0]
115        return y_true * logit - np.logaddexp(0, logit)
#

Returns the probability \(p\) of the positive class. Output Shape: (n_samples, 1)

116    def predict(self, y_pred: np.ndarray) -> np.ndarray:
117        logit = y_pred[:, 0]
118        prob = sigmoid(logit)
119        return prob.reshape(-1, 1)
#

The derivatives of the loss function (negative log likelihood) w.r.t. the model output (logit parameter \(z\)) are:

  • Gradient: \(\sigma(\text{z}) - y\)
  • Hessian: \(\sigma(\text{z}) \cdot (1 - \sigma(\text{z}))\)

where \(\sigma\) is the sigmoid function.

120    def gradient_hessian(
121        self, y_true: np.ndarray, y_pred: np.ndarray, weight: np.ndarray = None
122    ) -> Tuple[np.ndarray, np.ndarray]:
123        logit = y_pred[:, 0]
124        prob = sigmoid(logit)
125
126        grad = np.zeros_like(y_pred)
127        hess = np.zeros_like(grad)
128
129        grad[:, 0] = prob - y_true
130        hess[:, 0] = prob * (1 - prob)
131
132        if weight is not None:
133            weight = to_2d(weight)
134            grad *= weight
135            hess *= weight
136
137        return grad, hess
#

Returns initial logit based on mean probability (a priori). Note: $$p = \sigma(\text{z}) = \frac{1}{1 + e^{-\text{z}}} \implies \text{z} = \log \frac{p}{1-p}$$

138    def init_params(self, y):
139        mean_prob = np.clip(np.mean(y), 1e-7, 1 - 1e-7)
140        logit = np.log(mean_prob / (1 - mean_prob))
141        return np.array([logit])
142
143    mean = predict
#

Generate samples from the Bernoulli distribution given predictions.

144    def sample(
145        self, y_pred, n_samples: int, random_state: np.random.RandomState
146    ) -> np.ndarray:
147        logit = y_pred[:, 0]
148        prob = sigmoid(logit)
149        return random_state.binomial(1, prob, size=(len(prob), n_samples))

4.6 Utility Functions

This module contains a few utility functions that are used throughout the codebase. Nothing fancy here, except for the Numba aggregation function used to speed up histogram construction.

utils.py

#
1import math
2
3import numba as nb
4import numpy as np
#

Compute grouped sums of gradients and hessians for 2D arrays. Uses Numba for speedup. Input Shape: (n_samples, n_outputs) Output Shape: (n_groups, n_outputs)

 5@nb.njit
 6def groupby_sum_2d(
 7    n_groups: int,
 8    group_indices: np.ndarray,
 9    gradients: np.ndarray,
10    hessians: np.ndarray,
11    sample_weight: np.ndarray,
12):
13    n_outputs = gradients.shape[1]
14
15    grad_sums = np.empty((n_groups, n_outputs))
16    hess_sums = np.empty((n_groups, n_outputs))
17    weight_sums = np.bincount(group_indices, weights=sample_weight, minlength=n_groups)
18
19    for j in range(n_outputs):
20        grad_sums[:, j] = np.bincount(
21            group_indices, weights=gradients[:, j], minlength=n_groups
22        )
23        hess_sums[:, j] = np.bincount(
24            group_indices, weights=hessians[:, j], minlength=n_groups
25        )
26
27    return grad_sums, hess_sums, weight_sums
#

Map the values in the input array according to the provided mapping dictionary.

28def map_array(arr: np.ndarray, mapping: dict, missing_value=np.nan) -> np.ndarray:
29    return np.vectorize(lambda x: mapping.get(x, missing_value))(arr)
#

Ensure the input array is 2D. If 1D, reshape to (n_samples, 1).

30def to_2d(arr: np.ndarray) -> np.ndarray:
31    if arr.ndim == 1:
32        return arr.reshape(-1, 1)
33    elif arr.ndim > 2:
34        raise ValueError(f"Input array must be 1D or 2D, but got {arr.ndim}D.")
35    return arr
#

Compute the sigmoid function for each element in the input array. $$\sigma(x) = \frac{1}{1 + e^{-x}}$$

36@nb.njit
37def sigmoid(x: np.ndarray) -> np.ndarray:
38    return 1 / (1 + np.exp(-x))
#

Adaptively truncate a number based on a percentage of its magnitude. I use this pretty much everywhere to make sure numerical outputs don't look ugly.

39def trunc(num, threshold_percent=0.01, truncate_integer=False):
40    if num == 0:
41        return 0
42
43    sign = 1 if num > 0 else -1
44    num = abs(num)
45
46    min_change = num * (threshold_percent / 100)
47    decimal_places = math.ceil(-math.log10(min_change))
#

Check if we need to lose an additional decimal place

48    scale_d = 10 ** (decimal_places - 1)
49    digit_value_to_lose = ((num * scale_d) % 1) / scale_d
50    if min_change >= digit_value_to_lose:
51        decimal_places -= 1
#

Don't truncate integer digits unless explicitly allowed

52    if not truncate_integer:
53        decimal_places = max(decimal_places, 0)
54
55    scale = 10**decimal_places
56    truncated = int(num * scale) / scale
57    return sign * truncated

5 Experiments

Now that we have the implementation ready, let’s see how it performs on simple regression and classification tasks. We’ll use the Adult Census Income dataset for classification, and the California Housing dataset for regression

Install required packages

%pip install numpy pandas numba scikit-learn framedisplay --quiet

Add src (where the GBT implementation lives) to sys.path, and initialize FrameDisplay for better DataFrame visualization.

import sys
import framedisplay as fd

sys.path.insert(0, "./src")

fd.configure(dict(theme="ocean"))
fd.integrate_with_pandas()

5.1 Census Income Dataset

This is a binary classification task where the goal is to predict whether an individual’s income exceeds $50K/year based on a number of attributes such as age, education, occupation, etc. The dataset contains both numerical and categorical features, making it a good fit to test the capabilities of our implementation.

Load the data from Huggingface

import pandas as pd
import numpy as np

df_census = pd.read_csv(
    "https://huggingface.co/datasets/scikit-learn/adult-census-income/raw/main/adult.csv"
)
df_census.head(20)
age workclass fnlwgt education education.num marital.status occupation relationship race sex capital.gain capital.loss hours.per.week native.country income
0 90 ? 77053 HS-grad 9 Widowed ? Not-in-family White Female 0 4356 40 United-States <=50K
1 82 Private 132870 HS-grad 9 Widowed Exec-managerial Not-in-family White Female 0 4356 18 United-States <=50K
2 66 ? 186061 Some-college 10 Widowed ? Unmarried Black Female 0 4356 40 United-States <=50K
3 54 Private 140359 7th-8th 4 Divorced Machine-op-inspct Unmarried White Female 0 3900 40 United-States <=50K
4 41 Private 264663 Some-college 10 Separated Prof-specialty Own-child White Female 0 3900 40 United-States <=50K
5 34 Private 216864 HS-grad 9 Divorced Other-service Unmarried White Female 0 3770 45 United-States <=50K
6 38 Private 150601 10th 6 Separated Adm-clerical Unmarried White Male 0 3770 40 United-States <=50K
7 74 State-gov 88638 Doctorate 16 Never-married Prof-specialty Other-relative White Female 0 3683 20 United-States >50K
8 68 Federal-gov 422013 HS-grad 9 Divorced Prof-specialty Not-in-family White Female 0 3683 40 United-States <=50K
9 41 Private 70037 Some-college 10 Never-married Craft-repair Unmarried White Male 0 3004 60 ? >50K
10 45 Private 172274 Doctorate 16 Divorced Prof-specialty Unmarried Black Female 0 3004 35 United-States >50K
11 38 Self-emp-not-inc 164526 Prof-school 15 Never-married Prof-specialty Not-in-family White Male 0 2824 45 United-States >50K
12 52 Private 129177 Bachelors 13 Widowed Other-service Not-in-family White Female 0 2824 20 United-States >50K
13 32 Private 136204 Masters 14 Separated Exec-managerial Not-in-family White Male 0 2824 55 United-States >50K
14 51 ? 172175 Doctorate 16 Never-married ? Not-in-family White Male 0 2824 40 United-States >50K
15 46 Private 45363 Prof-school 15 Divorced Prof-specialty Not-in-family White Male 0 2824 40 United-States >50K
16 45 Private 172822 11th 7 Divorced Transport-moving Not-in-family White Male 0 2824 76 United-States >50K
17 57 Private 317847 Masters 14 Divorced Exec-managerial Not-in-family White Male 0 2824 50 United-States >50K
18 22 Private 119592 Assoc-acdm 12 Never-married Handlers-cleaners Not-in-family Black Male 0 2824 40 ? >50K
19 34 Private 203034 Bachelors 13 Separated Sales Not-in-family White Male 0 2824 50 United-States >50K
X = df_census.replace("?", np.nan).drop(columns=["income"])
y = (df_census["income"] == ">50K").astype(int).to_numpy()

Split the data into training and testing sets with stratification to preserve class distribution.

from sklearn.model_selection import train_test_split

X_train, X_test, y_train, y_test = train_test_split(
    X, y, stratify=y, test_size=0.2, random_state=42
)

Fit the model with Bernoulli distribution, since this is a binary classification task.

from src.gbm import GradientBoostedModel
from src.distributions import Bernoulli

dist_bernoulli = Bernoulli()
gbm = GradientBoostedModel(
    learning_rate=0.1,
    n_trees=50,
    n_leaves=20,
    max_depth=10,
    max_bins=255,
    max_categories=15,
    l2_regularization=0.0,
    min_weight_leaf=10,
    min_gain_to_split=0.0,
    goss_top_rate=0.3,
    goss_bottom_rate=0.1,
    goss_rescale_bottom=False,
    path_smoothing_strength=0.25,
    seed=42,
    feature_fraction=0.9,
    samples_fraction=0.8,
    distribution=dist_bernoulli,
    verbose=False,
)
gbm.fit(X_train, y_train);

This dataset has a few categorical features. Since max_categories is set to 15, those with more than 15 unique values will be treated as continuous features by encoding them using target statistics.

array = gbm.data_processor_.transform(X_test)
pd.DataFrame(array, columns=X_test.columns)[["native.country", "education", "race", "sex"]].head(10)
native.country education race sex
0 0.24591967894420672 0.4130081709599835 4.0 1.0
1 0.24591967894420672 0.1595181706586484 4.0 1.0
2 0.24591967894420672 0.4130081709599835 4.0 1.0
3 0.24591967894420672 0.7424649388331821 4.0 0.0
4 0.24591967894420672 0.1595181706586484 4.0 0.0
5 0.24591967894420672 0.1595181706586484 4.0 1.0
6 null 0.06636229734696716 4.0 1.0
7 0.24591967894420672 0.4130081709599835 2.0 0.0
8 0.24591967894420672 0.05338530176077435 2.0 1.0
9 0.24591967894420672 0.1595181706586484 4.0 0.0

We can see that some features like “race” have been transformed into integer codes while others with more unique values have been target-statistic encoded. The reason we use integer code rather than keeping original string values is that the transformed dataset is supposed to be a homogeneous float64 numpy array. So it’s more about implementation convenience.

This was just an example demonstrating the capabilities of the data processor.

Now let’s evaluate on the test set using F1-score and ROC-AUC.

from sklearn.metrics import f1_score, roc_auc_score
from src.utils import trunc

test_probs = gbm.predict(X_test)[:, 0]
class_labels = (test_probs >= 0.5).astype(int)
f1 = f1_score(y_test, class_labels, average="binary")
roc_auc = roc_auc_score(y_test, test_probs)
print(f"Test F1 Score: {trunc(f1)}")
print(f"Test ROC AUC Score: {trunc(roc_auc)}")
Test F1 Score: 0.6942
Test ROC AUC Score: 0.9194

Plot the confusion matrix

Code
from sklearn.metrics import confusion_matrix, ConfusionMatrixDisplay
import matplotlib.pyplot as plt

cm = confusion_matrix(y_test, class_labels)
fig, ax = plt.subplots(figsize=(6, 5), dpi=300)
ConfusionMatrixDisplay(cm, display_labels=["<=50K", ">50K"]).plot(ax=ax)
plt.title("Confusion Matrix")
plt.show()

Plot the ROC curve. The ROC curve summarizes the trade-off between true positive rate and false positive rate as we vary the decision threshold.

Code
import matplotlib.pyplot as plt
from sklearn.metrics import roc_curve, auc

fpr, tpr, thresholds = roc_curve(y_test, test_probs)
roc_auc = auc(fpr, tpr)
plt.figure(figsize=(7, 6), dpi=200)
plt.plot(fpr, tpr, color="blue", label=f"ROC curve (area = {roc_auc:.2f})")
plt.plot([0, 1], [0, 1], color="red", linestyle="--")
plt.xlim([0.0, 1.0])
plt.ylim([0.0, 1.05])
plt.xlabel("False Positive Rate")
plt.ylabel("True Positive Rate")
plt.title("ROC Curve")
plt.legend(loc="lower right")
plt.show()

Let’s now train and evaluate an LightGBM model with similar hyperparameters.

%pip install lightgbm --quiet

import lightgbm as lgb

categorical_cols = list(X_train.select_dtypes(include=["object", "category"]).columns)

X_train2 = X_train.copy()
X_test2 = X_test.copy()
X_train2[categorical_cols] = X_train2[categorical_cols].astype("category")
for col in categorical_cols:
    X_test2[col] = pd.Categorical(X_test2[col], categories=X_train2[col].cat.categories)

lgb_train = lgb.Dataset(X_train2, y_train, categorical_feature=categorical_cols)
lgb_eval = lgb.Dataset(X_test2, y_test, reference=lgb_train, categorical_feature=categorical_cols)
lgbm = lgb.LGBMClassifier(
    objective="binary",
    learning_rate=0.1,
    n_estimators=50,
    num_leaves=20,
    max_depth=10,
    min_data_in_leaf=20,
    reg_lambda=0.0,
    data_sample_strategy="goss",
    top_rate=0.3,
    other_rate=0.1,
    feature_fraction=0.9,
    bagging_fraction=0.8,
    seed=42,
    verbose=-1,
    path_smooth=0.25,
)
lgbm.fit(X_train2, y_train)


lgbm_test_probs = lgbm.predict_proba(X_test2)[:, 1]
class_labels = (lgbm_test_probs >= 0.5).astype(int)
f1 = f1_score(y_test, class_labels, average="binary")
roc_auc = roc_auc_score(y_test, lgbm_test_probs)
print(f"Test F1 Score: {trunc(f1)}")
print(f"Test ROC AUC Score: {trunc(roc_auc)}")
Note: you may need to restart the kernel to use updated packages.
Test F1 Score: 0.69808
Test ROC AUC Score: 0.9208

We can see they have similar performance. To make it complete let’s include CatBoost in the comparison as well:

%pip install catboost --quiet

import catboost as cb

categorical_cols = list(X_train.select_dtypes(include=["object", "category"]).columns)

X_train_cb = X_train.copy()
X_test_cb = X_test.copy()
for col in categorical_cols:
    X_train_cb[col] = X_train_cb[col].replace({np.nan: None}).astype(str)
    X_test_cb[col] = X_test_cb[col].replace({np.nan: None}).astype(str)

train_pool = cb.Pool(X_train_cb, y_train, cat_features=categorical_cols)
val_pool = cb.Pool(X_test_cb, y_test, cat_features=categorical_cols)

catboost_model = cb.CatBoostClassifier(
    loss_function="Logloss",
    iterations=50,
    learning_rate=0.1,
    depth=10,
    l2_leaf_reg=0.0,
    random_seed=42,
    verbose=0,
    allow_writing_files=False,
)
catboost_model.fit(train_pool)


cb_test_probs = catboost_model.predict_proba(val_pool)[:, 1]
class_labels = (cb_test_probs >= 0.5).astype(int)
f1 = f1_score(y_test, class_labels, average="binary")
roc_auc = roc_auc_score(y_test, cb_test_probs)
print(f"Test F1 Score: {trunc(f1)}")
print(f"Test ROC AUC Score: {trunc(roc_auc)}")
Note: you may need to restart the kernel to use updated packages.
Test F1 Score: 0.6861
Test ROC AUC Score: 0.9162

The performance across all three implementations is comparable, demonstrating that our implementation captures the essential components of modern GBT algorithms while remaining simple and extensible.

5.2 California Housing Price

This dataset contains information about house prices in California, including features like median income, average house age, average number of rooms, etc. The target variable is the median house value for each district. All features are numerical.

import numpy as np
import pandas as pd
from sklearn.datasets import fetch_california_housing

X, y = fetch_california_housing(return_X_y=True, as_frame=True)
X.head(20)
MedInc HouseAge AveRooms AveBedrms Population AveOccup Latitude Longitude
0 8.3252 41.0 6.984126984126984 1.0238095238095237 322.0 2.5555555555555554 37.88 -122.23
1 8.3014 21.0 6.238137082601054 0.9718804920913884 2401.0 2.109841827768014 37.86 -122.22
2 7.2574 52.0 8.288135593220339 1.073446327683616 496.0 2.8022598870056497 37.85 -122.24
3 5.6431 52.0 5.8173515981735155 1.0730593607305936 558.0 2.547945205479452 37.85 -122.25
4 3.8462 52.0 6.281853281853282 1.0810810810810811 565.0 2.1814671814671813 37.85 -122.25
5 4.0368 52.0 4.761658031088083 1.1036269430051813 413.0 2.139896373056995 37.85 -122.25
6 3.6591 52.0 4.9319066147859925 0.9513618677042801 1094.0 2.1284046692607004 37.84 -122.25
7 3.12 52.0 4.797527047913447 1.061823802163833 1157.0 1.7882534775888717 37.84 -122.25
8 2.0804 42.0 4.294117647058823 1.1176470588235294 1206.0 2.026890756302521 37.84 -122.26
9 3.6912 52.0 4.970588235294118 0.9901960784313726 1551.0 2.172268907563025 37.84 -122.25
10 3.2031 52.0 5.477611940298507 1.0796019900497513 910.0 2.263681592039801 37.85 -122.26
11 3.2705 52.0 4.772479564032698 1.0245231607629428 1504.0 2.0490463215258856 37.85 -122.26
12 3.075 52.0 5.322649572649572 1.0128205128205128 1098.0 2.3461538461538463 37.85 -122.26
13 2.6736 52.0 4.0 1.0977011494252873 345.0 1.9827586206896552 37.84 -122.26
14 1.9167 52.0 4.262903225806451 1.0096774193548388 1212.0 1.9548387096774194 37.85 -122.26
15 2.125 50.0 4.242424242424242 1.071969696969697 697.0 2.640151515151515 37.85 -122.26
16 2.775 52.0 5.9395770392749245 1.0483383685800605 793.0 2.395770392749245 37.85 -122.27
17 2.1202 52.0 4.052805280528053 0.966996699669967 648.0 2.1386138613861387 37.85 -122.27
18 1.9911 50.0 5.343675417661098 1.0859188544152745 990.0 2.3627684964200477 37.84 -122.26
19 2.6033 52.0 5.465454545454546 1.0836363636363637 690.0 2.5090909090909093 37.84 -122.27

Split the data into training and testing sets, with stratification to ensure the target distribution is (somewhat) preserved in both sets.

from sklearn.model_selection import train_test_split

X_train, X_test, y_train, y_test = train_test_split(
    X,
    y,
    stratify=np.digitize(y, bins=np.histogram_bin_edges(y, bins=10)),
    test_size=0.2,
    random_state=42,
)

Fit the model to the training data using Gaussian distribution. By using learn_variance=True, the model will also learn to predict the variance of the target for heteroscedastic uncertainty estimation.

from src.gbm import GradientBoostedModel
from src.distributions import Gaussian

dist_normal = Gaussian(learn_variance=True)
gbm = GradientBoostedModel(
    learning_rate=0.1,
    n_trees=50,
    n_leaves=20,
    max_depth=10,
    max_bins=255,
    l2_regularization=0,
    min_weight_leaf=20,
    min_gain_to_split=0.0,
    goss_top_rate=0.3,
    goss_bottom_rate=0.1,
    seed=42,
    feature_fraction=0.9,
    samples_fraction=0.8,
    distribution=dist_normal,
    verbose=False,
)
gbm.fit(X_train, y_train);
import numpy as np

# Shape (n_samples, 2), having (mean, stdev) for each sample
test_predictions = gbm.predict(X_test)
squared_errors = (test_predictions[:, 0] - y_test.values) ** 2
test_rmse = np.sqrt(np.mean(squared_errors))
print(f"Test RMSE: {trunc(test_rmse)}")

test_pearson = np.corrcoef(test_predictions[:, 0], y_test.values)[0, 1]
print(f"Test Pearson Correlation: {trunc(test_pearson)}")
Test RMSE: 0.4914
Test Pearson Correlation: 0.9087

Plot the calibration curve to visualize how well the predictions align with the true values across different ranges. Deviations from the line indicate regions where the model tends to under- or over-predict.

Code
import matplotlib.pyplot as plt
import seaborn as sns

fig, ax = plt.subplots(figsize=(7, 6), dpi=300)
# Calibration plot
sns.scatterplot(x=y_test, y=test_predictions[:, 0], alpha=0.9, ax=ax)
ax.set_xlabel("True Values")
ax.set_ylabel("Predicted Values")
# Set equal limits for x and y axes
min_val = min(y_test.min(), test_predictions[:, 0].min())
max_val = max(y_test.max(), test_predictions[:, 0].max())
ax.set_xlim(min_val, max_val)
ax.set_ylim(min_val, max_val)
ax.plot([min_val, max_val], [min_val, max_val], color="red", linestyle="--");

Code
mu, sigma = test_predictions.T
cv = sigma / mu

fig, ax = plt.subplots(figsize=(12, 5), dpi=300)
# mu-cv plot
sns.scatterplot(x=mu, y=cv, alpha=0.5, ax=ax)
ax.set_xlabel("Predicted Mean (μ)")
ax.set_ylabel("Coefficient of Variation (σ/μ)");

6 Final thoughts

I hope you found this implementation and explanation useful. I encourage you to try it out and experiment with different loss functions, and perhaps even extend it further. I had many ideas that I didn’t have time to implement such as dynamic learning rates, gradient-based binning, bagging, monotonic constraints, natural gradients, and different gain formulations. There are also engineering opportunities like early stopping and optimized histogram construction, to name a few. Maybe I’ll make another post about those in the future.

Thank you for reading this far. Feel free to ask any questions or provide feedback!

Reuse

Citation

BibTeX citation:
@online{sarang2025,
  author = {Sarang, Nima},
  title = {Implementing {Gradient} {Boosted} {Tree} {Algorithms} from
    {Scratch} - {LightGBM,} {XGBoost,} {CatBoost}},
  date = {2025-12-14},
  url = {https://www.nimasarang.com/blog/2025-12-14-gbt-algorithms/},
  langid = {en}
}
For attribution, please cite this work as:
Nima Sarang. Implementing Gradient Boosted Tree Algorithms from Scratch - LightGBM, XGBoost, CatBoost, 2025. Available: https://www.nimasarang.com/blog/2025-12-14-gbt-algorithms/.
